Suitable Properties of liquid for PumpSet |
||
|---|---|---|
| Specific Gravity: | 1.004 (max.) | |
| Chloride content: | 500 ppm (max.) | |
| Turbidity: | 50 ppm. Silica scale (max.) | |
| Allowable Solids: | 3000 ppm. (max.) | |
| pH Value: | 6.5 to 8.5 | |
| Max. Temperature: | 33°C (max.) | |
| Permissible Amt. of Sand: | 25 grams/cu. meter (max.) | |
| Hardness: | 300 (max.) | |
| Viscosity: | 1750000 m2/sec (max.) | |
Material of Construction |
||
|---|---|---|
| Part Name | Material | |
| Suction Casing | Grey Cast Iron or AISI 304 or AISI 316 | |
| Suction Bush | Nitrile Rubber | |
| DOL Bush | Nitrile Rubber | |
| Suction Plate | Technopolymer | |
| Pump Shaft | Chromium Steel | |
| Coupler | Chromium Steel | |
| Impeller | Technopolymer | Diffuser Bowl | Technopolymer |
| Discharge Outlet | Grey Cast Iron or AISI 304 or AISI 316 | |
| MODEL | STAGE | RATING | l/sec | 0.0 | 0.3 | 0.6 | 0.8 | 1.0 | G Ø Outlet (Inch.) | |
|---|---|---|---|---|---|---|---|---|---|---|
| m³/h | 0 | 1.2 | 2.2 | 2.7 | 3.7 | |||||
| HP | kW | l/min | 0 | 20 | 36.0 | 45 | 62 | |||
| 3GR001AA-12-SL | 12 | 1.00 | 0.75 | Head in Mtr. | 44 | 38 | 33.4 | 26 | 15 | 1.25" |
| 3GR001AA-15-SL | 15 | 1.00 | 0.75 | 56 | 48 | 41.7 | 30 | 23 | 1.25" | |
| MODEL | G Ø Outlet (Inch.) | Height (H) | Width(W) | Weight | Volume | |||
|---|---|---|---|---|---|---|---|---|
| mm | ft. | mm | ft. | Kg | lb | cu.ft | ||
| 3GR001AA-12-SL | 1.25" | 580 | 1.90 | 72 | 0.24 | 4.15 | 9.15 | 0.30 |
| 3GR001AA-15-SL | 670 | 2.20 | 72 | 0.24 | 4.48 | 9.88 | 0.34 | |
