Suitable Properties of liquid for PumpSet |
||
---|---|---|
Specific Gravity: | 1.004 (max.) | |
Chloride content: | 500 ppm (max.) | |
Turbidity: | 50 ppm. Silica scale (max.) | |
Allowable Solids: | 3000 ppm. (max.) | |
pH Value: | 6.5 to 8.5 | |
Max. Temperature: | 33°C (max.) | |
Permissible Amt. of Sand: | 25 grams/cu. meter (max.) | |
Hardness: | 300 (max.) | |
Viscosity: | 1750000 m2/sec (max.) |
Material of Construction |
||
---|---|---|
Part Name | Material | |
Suction Casing | Grey Cast Iron or AISI 304 or AISI 316 | |
Suction Bush | Leaded Tin Bronze | |
DOL Bush | Leaded Tin Bronze | |
Suction Plate | Grey Cast Iron or AISI 304 or AISI 316 | |
Pump Shaft | Chromium Steel | |
Coupler | Chromium Steel | |
Impeller | Technopolymer or Chromium Steel | Diffuser Bowl | Grey Cast Iron or AISI 304 or AISI 316 |
Discharge Outlet | Grey Cast Iron or AISI 304 or AISI 316 |
MODEL | STAGE | REQUIRED | l/sec | 0.0 | 2.3 | 2.8 | 3.2 | 3.5 | 3.8 | 4.1 | 4.7 | G Ø Outlet (Inch.) | |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|
m³/h | 0.0 | 8.4 | 10.2 | 11.4 | 12.6 | 13.8 | 14.7 | 16.8 | |||||
HP | kW | l/min | 0.0 | 140.0 | 170.0 | 190.0 | 210.0 | 230.0 | 245.0 | 280.0 | |||
6ER012AH-04 | 4 | 4.00 | 3.00 | Head in Mtr. | 83 | 72 | 64 | 60.0 | 56 | 48 | 40 | 30 | 2" |
6ER012AH-05 | 5 | 5.00 | 3.70 | 104 | 90 | 80 | 75.0 | 70 | 60 | 50 | 38 | ||
6ER012AH-06 | 6 | 6.00 | 4.50 | 125 | 108 | 96 | 90.0 | 84 | 72 | 60 | 45 | ||
6ER012AH-08 | 8 | 7.50 | 5.50 | 166 | 144 | 128 | 120.0 | 112 | 96 | 80 | 60 | ||
6ER012AH-10 | 10 | 10 | 7.50 | 208 | 180 | 160 | 150.0 | 140 | 120 | 100 | 75 | ||
6ER012AH-12 | 12 | 12.5 | 9.30 | 250 | 216 | 192 | 180.0 | 168 | 144 | 120 | 90 | ||
6ER012AH-15 | 15 | 15 | 11.00 | 312 | 270 | 240 | 225.0 | 210 | 180 | 150 | 113 | ||
6ER012AH-17 | 17 | 17.5 | 13.00 | 354 | 306 | 272 | 255.0 | 238 | 204 | 170 | 128 | ||
6ER012AH-20 | 20 | 20.0 | 15.00 | 416 | 360 | 320 | 300.0 | 280 | 240 | 200 | 150 |
MODEL | G Ø Outlet (Inch.) | Height (H) | Width(W) | Weight | Volume | |||
---|---|---|---|---|---|---|---|---|
mm | ft. | mm | ft. | Kg | lb | cu.ft | ||
6ER012AH-04 | 2" | 408 | 1.34 | 146 | 0.48 | 20.17 | 44.46 | 0.53 |
6ER012AH-05 | 440 | 1.44 | 146 | 0.48 | 21.65 | 47.74 | 0.56 | |
6ER012AH-06 | 472 | 1.55 | 146 | 0.48 | 23.14 | 51.01 | 0.60 | |
6ER012AH-08 | 536 | 1.76 | 146 | 0.48 | 26.11 | 57.56 | 0.66 | |
6ER012AH-10 | 600 | 1.97 | 146 | 0.48 | 29.08 | 64.12 | 0.73 | |
6ER012AH-12 | 664 | 2.18 | 146 | 0.48 | 32.05 | 70.67 | 0.80 | |
6ER012AH-15 | 760 | 2.49 | 146 | 0.48 | 36.51 | 80.50 | 0.90 | |
6ER012AH-17 | 824 | 2.70 | 146 | 0.48 | 39.49 | 87.05 | 0.96 | |
6ER012AH-20 | 920 | 3.02 | 146 | 0.48 | 43.94 | 96.88 | 1.07 |
